高清爱莎测试卡系列(三) Esser test charts


查看大图

高清爱莎测试卡系列(三) Esser test charts

HDTV 高清爱莎测试卡系列 Esser test charts ,ESSER摄像机测试卡(ESSER TEST CHART),摄像机测试卡应该是视频摄象机日常使用及定期检修时必备的工具,一套符合标准的测试卡更是不可缺少的。
销售价
面议 [ ¥0]
货  号:
G4F5174BCA9A08
品  牌:
  • 商品详情
  • 商品咨询 ( 0 )

HDTV 高清爱莎测试卡系列 Esser test charts

由成立于1998年TILO天友利专业代理,TILO是行业工商许可的数码图像检测用照明光源的生产型企业,通过ISO9001国际质量管理体系认证。



★★★★★第31届省港杯足球赛由天友利冠名赞助

★★★★★本公司通过ISO9001:2008国际质量管理体系认证

★★★★★本公司通过CE、RoHS、SCM等产品认证和检测

NO.                                                 Designation

no

designation

TE115 16:9

White Balance Chart 70% Reflectance

The TE 115 chart is designed for white balance. The density of the white area is 0.15 (based on BaO4S=0). This corresponds to a remission of 70%.

TE116 16:9

HDTV Grid Test Chart

The TE116 is designed for operational adjustment and control of HDTV cameras. It consists of circles permitting rough visual appraisal of scan linearity, lines serve the purpose of adjusting registration and wedges serve the purpose of resolution appraisal.

TE117 16:9

HDTV Universal Test Chart

The TE117 is designed for quick (mainly visual) appraisal of transmission characteristics of HDTV cameras. It consists of a gray background on which circles, gray scales, horizontal and vertical lines are positioned.

TE118 16:9

HDTV Resolution Test Chart (100 - 600 c/ph)The TE118 is designed for checking the resolution characteristics of HDTV cameras. On a black background five fields with different line rasters and black and white reference fields are arranged. The line rasters are inclined in different angles.

TE124 16:9

HDTV Resolution Test Chart  (100 - 600 c/ph)The TE124 is designed for checking the resolution characteristics of HDTV cameras.The test chart with an aspect ratio of 16:9 shows nine blocks containing 42 resolution patterns each in the middle area. The corner fields have 20 resolution patterns.

TE125 16:9

HDTV Zone Plate Test Chart (600 c/ph, asymmetric)The TE125 zone plate test chart is particularly suited for the visual determination of the resolution of a high definition camera. It shows asymmetrically arranged one zone plate ranging from 0 to 600 c/ph and two zone plate sectors with their centers located in the left corners. The gore-shaped gaps are gray.

TE128 16:9

ITE High Resolution Chart

The TE128 is designed for measuring and quick (most visual) appraisal of transmission characteristics of high resolution non-broadcast cameras. It consists of a gray background, a white circle, gray scales, multibursts, resolution wedges with different frequencies (vertical + horizontal) circular rings.

TE167 16:9

HDTV Universal Test Chart

The TE167 test chart is designed for general appraisal of HDTV cameras. It consists of gray scales, circular figures, a grid, sector stars, multibursts and resolution wedges.

TE200

Sony HDTV Set Up Test Chart

The SONY HDTV Setup Test Chart is determined for setting up all Sony cameras which are switchable between 4:3 and 16:9 aspect ratio. It consists of a gray background with grid structure and two 3-step-gray scales in center of the chart.

TE222 16:9

HDTV Color Resolution Test Chart

The TE222 is designed to measure color resolution of HD cameras. R, G, B, BY and MC multiburst patterns from 2 MHz to 20 MHz are on the chart

TE223 16:9

HDTV Log. Gray Scale Test Chart, 13 steps, contrast 1:200

The TE223 is designed for evaluation of the halftone reproduction of electronic cameras. Two 13-graduated counter current gray scales are arranged on a gray background. The gray scales being graduated logarithmically.

TE224 16:9

HDTV  Resolution Test Chart

The TE224 is designed to measure and describe the frequency response of an electronic HDTV camera. The test chart consists of 50 multi burst fields, which are distributed over a 16:9 picture area. The fields are arranged in horizontal and vertical direction to measure resolution in both directions.

TE225 16:9

HDTV  Resolution Test Chart

The TE225 is designed to measure and describe the frequency response of an electronic HDTV camera. The test chart consists of 32 multi burst fields, which are distributed over 16:9 picture area. The fields are arranged in horizontal and vertical direction to measure resolution in both directions.

TE226 16:9

HDTV Color Rendition Test Chart

The TE226 is designed for evaluation color rendition of HDTV cameras. The chart consists of 36 color patches and a 9-step gray scale. Besides the primary and secondary colors the test chart contains mainly colors, which are critical in reproduction, e.g. dark and light skin tones, foliage, blue sky, orange, violet and others.

TE231 N 16:9

HD Sweep Test Chart

The TE231 is designed for checking the frequency response of HDTV cameras. The test chart shows line rasters over the whole image area ranging from 100 to 1200 lines.

TE232 16:9

Log. Gray Scale/Color Test Chart 16:9 (super black hole in folders)The TE232 is designed for evaluation of the halftone and color reproduction of electronic cameras. Two 11-graduated counter current gray scales are arranged on a gray background (graduated logarithmically) and two color patches representing the three primary colors as well as the three secondary colors.

TE233 16:9

Color Chart with 24 colors and 4 skin tones

The TE233 serves for measuring the color reproduction of HD cameras, for selective color correction and for making color reference shootings for post production. The chart is composed of color patches including the three basic colors, the secondary colors and patches with four skin tones.

TE234 16:9

Color Gradation Test Chart

The TE234 consists of different color grades. It is used to check quantization errors which results in visible steps in the grades.

TE239 16:9

HDTV In Mega Cycle Test Chart

The TE239 is designed for checking the frequency response of modulation depth and the uniformity of modulation depth of HDTV cameras. The test chart consists of multi burst fields, which are distributed over a 16:9 picture area.The fields are arranged in horizontal and vertical direction to measure resolution in both directions.

TE246 16:9

4 Quadrant Sector Star

The special star consists of four segments each with a different number of cycles. So it is possible to focus the wide angle and the tele position in an optimal adjustment of the focusing point. This is essential for positioning the flange focal distance without a special collimator.

TE253

Modulated Sinusoidal Siemens Star

The TE253 is designed for checking resolution. The chart contains a radially sine modulated Siemens star in the center of the image, gray patches and black squares with a small white square in it.

TE256 16:9

Color and Calibration Test Chart revised Version of  TE232(super black hole in folders)The TE256 is designed to color align HD cameras.

TE259

OECF/Noise Chart with 20 gray patches contrast 10000:1

The TE259 is designed to check the dynamic range of broadcasting cameras on a waveform monitor. It contains a gray step wedge with 20 patches and a contrast range of 10000:1.
